Baldor-Reliance

Model # :WBB388095

MPN #: CJM3155

Baldor-Reliance Motor CJM3155, 2HP, 3450RPM, 3PH, 60HZ, 56J, 3430M, OPEN, F1

Product Description
Baldor-Reliance Motor, 2HP,3450RPM,3PH,60HZ,56J,3430M,OPEN,F1

Features:
  • Diecast aluminum end plates with machined steel bearing seat insert.
Typical Applications:
Residential and industrial pumps, swimming pool pumps, etc.

PRICE
$895.00

1
1
Ships in 2 Business Days
Add or Change Zip Code(s)
Easy online or call-in returns. Read return policy

Key Specifications

BrandBaldor-Reliance

Weights & Dimensions

Weight36 lbs
Dimension C13-3/4 in

Product Details

Power Factor86
Bearing Opp Drive End6203
Drive End FlangeC-Face
KVA CodeL
Motor RPM 60 Hertz3450 rpm
Mounting LocationRigid
Phase3
Manufacturers Part NumberCJM3155
EnclosureOPEN
Service Factor1.2
Bearing Drive End6203
RPM3,450 rpm
Insulation ClassB
Horsepower2 HP
Frame56J
Hertz60 Hz
Design CodeB
Amps @ 208V6.4 A
Enclosure TypeOpen/Drip Proof
Voltage230, 460 V
Full Load Efficiency82.5
Full Load Amps5.4/2.7 FLA
Poles2
Ambient Temperature40 °C
RPM Range3001-3600 rpm
